* In CE-6000, E indicates the energy feedback function.
* Other model can be customised to according to the voltage and current requirements (200V ~ 1000V, 100A ~ 1000A).
- Tests battery pack performance for battery manufacturers, EV manufacturers, and energy storage comalnies.
- Supports comprehensive performance indicators testing such as cycle life, capacity, efficiency, working conditions, float performance, SOC, DOD, and rate.
- Can recover and redistribute energy produced by battery discharge.
- Adopts AC/DC, DC/DC dual-stage high frequency isolation modular design, combined with low temperature drift, high performance multichannel 24-bit ADC chip, and steady state accuracy is higher than traditional equipment.
- The charge and discharge testing system and environmental test chamber can be controlled uniformly from a PC.
Technical Specifications
Precision engineering for accurate measurements
| Power 100kW | Voltage 500V | Current 200A |
|---|---|---|
| Power 150kW | Voltage 750V | Current 200A |
| Power 300kW | Voltage 1000V | Current 300A |
Methods/Techniques
DOD SOC float performanceworking conditions
